FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness

    Buy cheap FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness from wholesalers

    Buy cheap FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness from wholesalers
    • Buy cheap FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness from wholesalers
    • Buy cheap FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness from wholesalers
    • Buy cheap FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness from wholesalers
    • Buy cheap FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness from wholesalers

    FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness

    Ask Lasest Price
    Brand Name : BLM-IV-1
    Price : USD18-19/KG
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 300 Ton/Tons per Month
    Delivery Time : 20-40 days
    • Product Details
    • Company Profile

    FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness


    Hot sale direct price invar 36 wire,invar 36 strip,invar material


    1.Descriptions:


    INVAR 36 is a nickel-iron, low-expansion alloy containing 36% nickel. It maintains nearly constant dimensions over the range of normal atmospheric temperatures, and has a low coefficient of expansion from cryogenic temperatures to about 500°F. The alloy also retains good strength and toughness at cryogenic temperatures.

    INVAR 36 can be hot and cold formed and machined using processes similar to austenitic stainless steels. INVAR 36 is weldable using Filler Metal CF36 which is available in bare wire for both the GTAW and GMAW process.


    Product NameInvar 36 Plate ASTM,ASTM GB
    TypeInvar Plate
    Surface TreatmentBlack
    Applicationpetrochemical industry
    Tooling and dies for composite forming
    Cryogenic components
    Laser components
    InventoryINVAR 36 Plate, INVAR 36 Weld Wire
    FeaturesLow expansion rate up to 500°F
    Readily weldable
    SpecificationsAFNOR NF A54-301 (chemistry only), ASTM F 1684-06, EN 1.3912, UNS K93600, UNS K93603, Werkstoff 1.3912
    Common Trade NamesNilo 36
    Place of OriginJiangsu, China (Mainland)
    Delivery25-30 days subject to the clients' requirements and quantity

    2 . Specification:


    GB/TUNSAISI/ASTMW.Nr
    4J36K93600InVAR 361.3912

    3 . Chemical Composition:

    GradeNiCrFeCMnSiCoMoPS
    Invar 36Min35bal0.2
    Max370.50.050.60.310.50.020.02

    4 . Mechanical Properties:


    GradeTensile Strength Rm N/mm²Yield Strength Rp0.2 N/mm²Elongation A5 %Hardness
    Invar 3649024042HB≤200

    5 . Applications:

    • Advanced composite molds for aerospace industry
    • Bimetal thermostats
    • Clock balance wheels
    • Containers for LNG tankers
    • CRT applications: Shadow masks, deflection clips and electron gun components
    • Dimensionally stable instruments and optical devices
    • Echo boxes and filters for mobile telephones
    • Electrical circuit breakers
    • High voltage transmission lines
    • Magnetic shielding
    • Metrology devices
    • Pendulum clocks
    • Positioning devices
    • Precision condenser blades
    • Radar and microwave cavity resonators
    • Scientific instruments
    • Seals, spacers and specialized frames
    • Small electrical transformers
    • Special electronic housings
    • Temperature regulators
    • Transfer lines for LNG

    6 . More pictures


    FeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm ThicknessFeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm ThicknessFeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm ThicknessFeNi36 Grade Invar 36 Wire , Invar 36 Strip 8mm - 100mm Thickness
