    Extruder Screw Barrel And Spare Parts For Coperion Twin Screw Extruder

    Ask Lasest Price
    Brand Name : Bloom
    Model Number : BLM
    Certification : ISO 9001
    Price : Negetation
    Payment Terms : T/T
    Supply Ability : 1000mm/month
    Delivery Time : 30 to 45 days
    • Product Details
    • Company Profile

    Extruder Screw Barrel And Spare Parts For Coperion Twin Screw Extruder

    Extruder Screw Barrel And Spare Parts For Coperion Twin Screw Extruder


    Bimetallic Screw Barrel For LDPE / HDPE / PP / PE / PVC Blowing Molding Machine


    1 . Description

    We are the manufacturer of supplier of screw and barrel in china,including designing,manufacturing and sales for these products,we can make any specification of extruder screw barrel and injection molding screw barrel for Engle,Nigrobossi,KMD,NPM,BOY,Haitian,Demag,HUSKY, Nippon Steel, Toshiba, Nissei,Mitsubishi and etc. We also can supply all types of screw and barrel according to your different requirements.

    Screw diameter:Φ15mm-Φ360mmL/D=15-56

    Length of screw and barrel/cylinder:8000mm


    According to different material and plastic products to design different screw structure ,compress rate and L/D.
    According to different material and plastic products to design different Barrel with exhaust system and IKV force load system.

    Color

    Bright

    Standard

    ISO 9001

    Grade

    Type 20 / 30 / 35 / 36 /40 /50 / 52 / 53 / 58 / 60 / 65 / 75 / 85 / 92 / 95 / 110 / 125 /135

    Brand

    Bloom

    Quality

    High wear - resistance adn corrosion resistance

    Used

    For twin screw extruder

    The cross-sectional area is changed by adjusting the flight lead and thread depth, effectively eliminating sudden cross-sectional deformation and impeding resin pooling and extrusion fluctuations. Our (Barrier Mixer) with its high rolling and chaos effects can be mounted on the barrier outlet and screw tip to further enhance kneading and output rate.

    2 . Standard Barrel Parameter Table (selection table)

    Standard Barrel Parameter Table (selection table)

    Model

    Size(mm) W.H.L

    Hole Diameter(mm)

    Center Distance(mm)

    BLM-20

    115.105.132

    Φ23

    18.4

    BLM-30

    135.115.120

    Φ30.6

    26

    BLM-35

    140.120.140

    Φ36

    30

    BLM-36

    160.140.150

    Φ36

    30

    BLM-40

    175.145.160

    Φ41.6

    34.5

    BLM-50

    190.150.190

    Φ51

    42

    BLM-52

    200.155.210

    Φ52

    43

    BLM-53

    210.160.220

    Φ53.3

    48

    BLM-58

    220.175.240

    Φ58

    48

    BLM-60

    210.170.240

    Φ60

    52

    BLM-65

    210.170.240

    Φ63

    52

    BLM-75

    260.200.290

    Φ71.8

    60

    BLM-85

    280.215.320

    Φ81.9

    67.8

    BLM-92

    310.240.360

    Φ92

    78

    BLM-95

    310.240.360

    Φ94

    78

    BLM-110

    330.240.420

    Φ109

    91.5

    BLM-125

    390.290.500

    Φ125

    98

    BLM-135

    370.300.410

    Φ134

    110


    3 . Barrel materials:

    We choose different kinds of materials for barrel according to different application.

    Normally,there are two main kinds of materials,one is HIP powder tool steel,and the other is domestic steel.



    Solid Barrel

    Material GrandEquivalent steels forRemarks
    BLOOM 0145Slight
    BLOOM 0242CrMoMedium
    BLOOM 0338CrMoAIaStrong

    Barrel with installed liner

    * made of PM-HIP solid *WR13
    By working closely with customers in choosing optional materials,we can minimize wear and tear and associated costs.


    Material Grand(HRC) HardnessApplication
    BLM Ni 0155-58Wear resistance
    BLM C0260-62Wear + corrosion
    BLM 0160-62Wear resiatance
    BLM 0260-62Wear resistance
    BLM 0360-62Wear resistance
    BLM 0459-61Wear resistance

    3 . Material & Processes of screw barrel for plastic extruder

    Alloy-steel of High-quality
    1)38CrMoAlA
    2)42CrMo
    3)9Cr18MoV
    4)CW6Mo5Cr4V2
    5)Quality Duplex Stainless Steels
    6)GH 113
    7)Quality Powder Metallurgy Raw Materials
    8)Cold/Thermal Spray Hard Metal process
    9)Advanced nitriding Process
    10)Corrosion & Abrasion Resistance Bimetal Spraying Process


    4 . Types

    Convey Screw Segment
    Mixing Screw Segment
    Kneading Block Disk
    Transition Screw Element
    Deep groove transfer element
    Screw element for side feeder
    1flighted 2flighted flighted screw elements


    5 . As per customer's demand,we can also supply below:
    PVC/PE Film Blowing Screw;

    Blow Molding Screw;

    PS/PE/PP/ABS Sheet Extrusion Screw;

    PE Aluminum Plate;

    PPR Pipe Screw;

    EVA Extrusion Screw;

    HDPE High efficiency Screw;

    PET Straps Screw;

    XPS/EPE Foamed Screw;

    Granulation Screw,Vented single screw etc.
